TSONIC TIME2110 TIME2110 Ultrasonic Thickness Gauge

Introduction

The model MT200 is a digital ultrasonic thickness gauge. Based on the same operating principles as SONAR, the MT200 is capable of measuring the thickness of various materials with accuracy as high as 0.01 millimeters, or 0.001inches. It is suitable for a variety of metallic and non-metallic materials.

Features

1) Capable of performing measurements on a wide range of material, including metals, plastic, ceramics, composites, epoxies, glass and other ultrasonic wave well-conductive materials.
2) Four transducer models are available for special application, including for coarse grain material and high temperature applications.
3) Probe-Zero function, Sound-Velocity-Calibration function
4) Two-Point Calibration function.
5) Two work modes: Single point mode and Scan mode.
6) Coupling status indicator showing the coupling status.
7) Battery information indicates the rest capacity of the battery.
8) Auto sleep and auto power off function to conserve battery life.
9) Optional software to process the memory data on the PC.
10) Optional thermal mini-printer to print the measured data via RS232 port.

Photos

Specifications

Display 128×64 dot matrix LCD with EL backlight.

Measuring Range 0.75~300mm (in Steel).

Sound Velocity Range 1000~9999 m/s.

Resolution 0.1/0.01mm(selectable).

Accuracy ±(0.5%Thickness+0.04)mm

Units Metric/English unit selectable.

Four measurements readings per second for single point measurement, and ten per second for Scan Mode.

Memory for 20 files (up to 99 values for each file) of stored values.

Upper and lower limit can be pre-set. It will alarm automatically when the result value exceeding the limit.

Power Supply Two “AA” size, 1.5 volt alkaline batteries. 100 hours typical operating time (EL backlight off).

Communication RS232 serial port.

Case Extruded aluminum body suitable for use under poor working conditions.

Company View

Workshop

Packaging

Certificates:

Services:

Quality:

Quality is the life of honesty. We use the best quality original components to ensure the standard

of our product range is of the highest caliber. All products we sold out are strictly selected and

Tested by our QC department.

Payment:

We accept payment via T/T(Bank transfer), L/C, Western Union, and Paypal for small amount.

Shipping:

We offer as many shipping options as possible, including DHL, UPS, TNT, FedEx and EMS

by air or by sea.

Warranty:

The product is guaranteed for 1 year from the date of delivery under normal condition.

Customers will enjoy free repair services within the warranty period due to product quality.

We provide paid repair services for products damage not arsing from manufacturing quality or not within the warranty.
